Oscilloscopio Rigol MSO5072 70MHz mixed signals Ciclo de las rocas Que es y cules son las etapas. L' Oscilloscopio digitale MSO5072 integra 7 strumenti indipendenti in 1 . Un oscilloscopio digitale , un analizzatore di stati logici , un analizzatore di spettro , un generatore di forme d'onda arbitrarie (opzione) , un voltmetro digitale , un misuratore di frequenza e totalizzatore , un analizzatore di protocollo (opzione). Specifiche tecniche: Several modes Digital Oscilloscope , Digital Voltmeter , Logic Analyzer , Arbitrary Waveform Generator (Option) , Spectrum Analyzer , High precision Frequency Counter and Totalizer , Protocol Analyzer (Option) Bandwidth 70 MHz Analog Channels 2 Digital Channels 16 Max. Sample Rate of Analog Channel 8 GSa s (single channel) Memory Depth 100 Mpts ( standard ) , 200 Mpts ( option ) Waveform Acquisition Rate 500,000 wfms s (Waveforms per Second) Max. Frames of Waveform Recording 450. 000 LCD 9 inch capacitive multi touch screen Hardware Mask Test Standard Built in Arbitrary Waveform Generator 2 CH, 25 MHz ( optional ) Built in Digital Voltmeter standard Interface Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB GPIB Built in Hardware Counter 6 digit frequency counter + totalizer Search and Navigation Standard supporting table display Power Analysis Built in UPA (optional) Serial Protocol Analysis RS232 UART, I2C, SPI, CAN, LIN, FlexRay, I2S, and MIL STD 1553 Waveform Color Persistance standard Datasheet serie Rigol MSO5000 User Guide serie Rigol MSO5000
